SC 100×300 Pneumatic Air Cylinder



SC series double acting standard gas cylinder/ air cylinder/ pneumatic cylinder: SC32/ SC40/ SC50/ SC63/ SC80/ SC100.

SC Series Pneumatic Air Cylinder

Product Description:

The SC double acting version of the compact cylinder is available for those bore cylinder applications where saving space is a concern. There are magnetic switch slots around the cylinder body, which is convenient to install sensor switch.

Product Features:

-Standard double acting type

-Bore sizes: 32~100mm

-Strokes from 32mm through 400mm

-Variety of switches and a variety of lead wire lengths

-Pressure: 0.1~1.0Mpa

-Temperature: -5~70℃

-Auto switch: CS1 series

Product Parameters:

Bore size (mm) 32 40 50 63 80 100 125 160 200 250
Fluid Air
Action Double acting, Single/Double rod
Minimum operating pressure 0.1 MPa
Maximum operating pressure 1.0 MPa
Proof pressure 1.5 MPa
Ambient and fluid temperature -20 to 80°C (No freezing)
Cushion Adjustable air cushion at both ends
Lubrication Non-lube
Piston rod dia. 12 mm 16 mm 20 mm 25 mm 32 mm 40 mm 50 mm
Weight 2.5 kg
Dimensions 120 × 350 × 120 mm
