Conveyor Belt Vulcanizing Machine
Description:
General type LD Series vulcanizing press machine takes Germany advanced technology, and based on the characteristics of the domestic industry. The product is suitable for width 680-2400mm conveyor belt joint and repair.
General type LD Series vulcanizing press machine is one of the company developed vulcanizer series, it is suitable for use in all types of non-explosive and dangerous security environment places. This device uses high-strength aluminum alloy light, easy to handle; stainless steel heating tube heating element, rapid heating, temperature uniformity; easy operation, long service life.
Pressure molding box pressure system: each pressure molding box with a pressure indicating instruments are available to the user according to the process requires accurate field adjustment. In the pressing process, the residual gases can be excluded rubber compound to improve the quality of bonding, can be fully compensated pressurized elastically deformable beam so that the joint area smooth, uniform pressure, uniform thickness. Use no pollution, no noise, no auxiliary equipment, maintenance-free.
Heating plate: using high-quality, high-strength aluminum alloy materials, design layout to ensure the consistency of temperature, heating up fast, even temperature. Special stainless steel heating pipe, having excellent insulating properties and corrosion resistance and high degree of protection. The cooling plate is cooled using water.
Temperature Control System: The curing temperature control system with automatic and manual control functions, the user can according to the actual vulcanization process requirements, convenient for curing temperature and constant time setting; and automatic thermostat and thermostatic temperature control unit through control time setting. All high-brightness temperature control box digital instrument display, clear and accurate reflection of the control operation, can automatically cut off the heating power after vulcanization is complete and sound and light tips.
Applicable conveyor type: General type LD Series vulcanizing press machine is suitable for various intensities of Fabric with rubber conveyor belt, steel cord rubber conveyor belt, mining PVC, PVG whole flame retardant conveyor belt, all kinds of flat-shaped rubber conveyor or conveyor belt splicing bonding and repair use.
Note:
The specification is just for reference, we can produce it according your requirement.
Specification:
- Suitable for Conveyor Width:680mm-2200mm
- Heating Plate Length: 600mm,900mm
- Cementing Angle0°:16.7°
- Curing Working Surface Temperature:≤175°C
- Curing Pressure:8Bar-12Bar
- Cooling Way: strong refrigeration/ Natural cold
- Application of Conveyor Belt Thickness:≤40mm
- Related Voltage: 380v (AC 3PH 50Hz)
